THE32 SUB PRO ACTIVE SEALED
Description
The The32 SUB PRO PASSIVE SEALED infrasub shifts the benchmarks.
Key figures: 82 cm / 32" custom-built super-woofer, 90 mm of linear travel – the world record for home theater or even commercial cinema subwoofers. The The32 SUB PRO plays in its own league. Authority and impact, speed, dynamics and differentiation, all these attributes the The32 SUB PRO evolves when playing down to the deepest notes in the single digit range. This opens up a new world in lowest bass reproduction. Any comparison will illustrate the sovereignty of its infrasonic bass capabilities.
Displacing an incredible volume of 16.6 liters or half a cubic foot, the The32 SUB PRO pushes as much air per maximum stroke as fifteen standard 18" subwoofers. The The32 SUB PRO allows not only to reproduce lower frequencies, but also a much faster group delay at the same frequencies than the commonly used 18”, 15” and 12" subwoofers in todays home theater and commercial cinema configurations.
The performance of the The32 SUB PRO is unparalleled. This infrasub complements both state-of-the-art cinemas or home theater setups to extend LFE channel reproduction or benefits the best high-end speakers. It dramatically improves the overall performance of all speaker systems.
The32 SUB PRO - more depth, image, structure, resolution, volume, dynamics equals more fun
Specification
General
Speaker Type
32” forward-firing woofer, with dual 6.5” voice coil
XMAX
45 mm Xmax excursion each direction (90 mm linear), voice coil remaining in homogeneous magnetic field
Principle
Sealed
Passive | Active
Active, built in DSP Amplifier
Measured Data
SPL Peak (Peak / Half Space 2pi)
Measured Data 140 dB @ 32 Hz and up 125 dB @ 20 Hz 109 dB @ 10 Hz
Frequency Range
Measured Data (without DSP) 28 Hz - 500 Hz / -3 dB 20 Hz - 500 Hz / -15 dB
Directivity Horizontal x Vertical in deg°
360°
Max Linear Air Volume Displacement
12.62 US. liq. gal. | 47.8 L
Power Specifications & Features
Output Power
6000 W
Power Supply Requirements
100-240 VAC, 50-60 Hz (Operating: 90-265 VAC)
Power Consumption
230 VAC - 1/8 rated power (4 Ohm)
4.5 A / 980 W
120 VAC - 1/8 rated power (4 Ohm)
8.6 A / 980 W
Idle
0.5 A / 61 W
Automatic Power Off
Trigger
Connections
Input
1 x XLR Balanced
Output
1 x XLR Balanced Link
Power
Neutrik powerCON True 1 in-out
Communications
2 x RJ45 / Daisy Chain
Signal Processing & Control
Protection Features
Turn-on transients, Over-heating, DC, RF, Short-circuit, mismatched loads, ICL™, PMS™
Controller
OCS Software Control
Converter
High Performance 96 kHz / 24 bits AD/DA converters, 64 bit double-precision 96 kHz DSP process
Input IIR EQ Section
Gain, Mute, Phase inversion, Delay (up to 116 ms, 40 m), 10 EQ filters (Parametric, Shelving, LP, HP, BP, SB, AP)
Dimensions & Weight
Dimensions (W/H/D) mm (Without Grille)
950 | 1225 | 550 (Height without feet: 1200) (Depth with plug: 550)
Dimensions (W/H/D) inch (Without Grille)
37 3/8 | 48 3/16 | 21 5/8 (Height without feet: 47 1/4) (Depth with plug: 21 5/8)
Packing Dimensions (W/H/D) mm
1200 | 1590 | 800
Packing Dimensions (W/H/D) inch
47 4/16 | 62 10/16 | 31 8/16
Weight
352.74 lbs | 160 kg
Gross Weight
421.08 lbs | 191 kg
Design & Mounting
Enclosure
Internally braced MDF
Finish
Structural paint black
Mounting
Floorstanding with feet
